Sheet Metal Design Guidelines That Reduce Manufacturing Cost by 20%

In today’s competitive manufacturing landscape, controlling fabrication cost without compromising quality is a strategic advantage. OEMs, industrial equipment manufacturers, and engineering firms are under constant pressure to reduce expenses while maintaining global compliance and performance standards.

One of the most effective ways to achieve a 15–20% cost reduction in fabrication is through optimized sheet metal design combined with adherence to ISO fabrication standards. When design-for-manufacturability (DFM) principles align with structured quality systems, manufacturers reduce waste, minimize rework, and ensure consistent output across international markets.

Below are proven sheet metal design guidelines that consistently reduce manufacturing costs while improving production efficiency.

Standardize Material Selection and Thickness

One of the most overlooked cost drivers in sheet metal fabrication is excessive material variation. Standard materials are typically stocked by most fabricators, which reduces procurement costs and lead times. Opt for common thicknesses, such as 0.8mm to 3mm, and grades like mild steel or aluminum 5052, which are readily available in bulk.

Using non-standard sizes often incurs premiums for special orders. This approach alone can save 5-10% on material expenses by minimizing waste from custom cuts.

Optimize for Sheet Nesting

Design parts to fit standard sheet sizes, such as 4×8 feet, maximizing nesting efficiency. Efficient nesting reduces scrap rates from 15% to under 5%, directly lowering material costs.

Software like AutoCAD or SolidWorks helps simulate nesting patterns early. Align flat patterns to avoid awkward shapes that leave excess waste.

Standardize Hole Sizes and Radii

Use standard punch sizes (e.g., 2.5mm, 4.5mm, 8mm) and consistent bend radii (1-2x material thickness). This eliminates tool changes, cutting setup time by 30-50%.

Avoid custom diameters unless essential, as they require special tooling. Consistent features across parts streamline production runs.

Simplify Bending Operations

Maintain minimum flange lengths (2-3x material thickness) and avoid holes near bends to prevent deformation. Consistent bend radii and angles reduce machine setups.

Position bends outside hems or hems to simplify tooling. This guideline optimizes bending sequences, saving labor and machine hours.

Use Appropriate Tolerances

Default to general tolerances (±0.5mm for most features) instead of tight specs (±0.1mm). Tight tolerances demand slower machining and extra inspections, inflating costs by 20-40%.

Only specify precision where functional needs dictate, like mating surfaces. Looser specs speed up fabrication without compromising assembly.

Minimize Tabs and Slots

Design self-locating assemblies with simple tabs and slots sized precisely for material thickness. Overly complex interlocking features increase cutting time and error rates.

Prefer fasteners over excessive welds for assembly, as welding adds heat distortion risks and post-processing. This reduces labor by favoring quicker mechanical joins.

Leverage Standard Components

Incorporate off-the-shelf fasteners, hinges, and handles instead of custom ones. These are cheaper, faster to source, and simplify repairs.

Standard parts cut inventory costs and assembly time. They also enable economies of scale in production.

Reduce Unnecessary Features

Eliminate non-functional elements like extra cutouts or decorative bends. Each added feature boosts machining time and scrap potential.

Apply lean principles: question every detail’s value. Streamlined designs lower overall complexity and costs.

Design for Efficient Welding and Assembly

Minimize welds by using bends or fasteners where possible. Position welds in accessible areas to cut fixturing needs.

Create designs with fewer parts for easier assembly. Use jigs for repeatability, balancing initial setup against long-term savings.

Prototype and Iterate Early

Test designs with rapid prototyping to catch costly issues pre-production. Tools like 3D product configurators simulate manufacturability.

Early feedback refines designs, avoiding expensive revisions. This step ensures guidelines are applied effectively.

Impact on Manufacturing Costs

Implementing these guidelines, standard materials, nesting, standardization, and simplification collectively reduces costs by 20%. Fabricators report savings from less waste (5-8%), faster setups (7-10%), and optimized labor (5%).

CAD software with DFM analysis, like SolidWorks or AutoCAD plugins, automates checks for bend radii and nesting. Advanced solutions integrate design automation for precise cost modeling.
